Short Circuit & Relay Coordination Study for 33 kV Industrial Network
Ensuring reliable fault protection for industrial power systems through detailed fault analysis, relay grading, and protection selectivity validation prior to commissioning.
Project Overview
Power Projects was engaged to perform a Short Circuit Study and Relay Coordination Study for a 33 kV industrial electrical network prior to system commissioning. The study focused on validating network behaviour under fault conditions and ensuring the protection system operates selectively, reliably and safely during abnormal system events.
In industrial power systems, protection performance plays a critical role in maintaining operational continuity. A single protection maloperation can lead to unnecessary feeder outages, extended downtime and, in severe cases, complete plant shutdown. The study was therefore undertaken to support safe energisation, improve system reliability and minimise operational risk.
The electrical system consisted of a medium-voltage distribution network supplying multiple downstream loads across different voltage levels. The study was carried out using DIgSILENT PowerFactory for detailed network modelling, fault simulations and protection coordination analysis.
For modelling efficiency, low-voltage switchboards and downstream 415 V loads were represented using aggregated load models while maintaining sufficient accuracy for system-level studies.
Study Objectives
The overall protection philosophy was designed to ensure that only the faulted section of the system is isolated while maintaining continuity of supply to the remaining network.
Validate short circuit levels across the network
Verify equipment withstand capability under fault conditions
Develop coordinated relay settings
Ensure selective fault isolation
Prevent unnecessary tripping of healthy feeders
Support stable and reliable plant operation during disturbances
Engineering Challenges
Managing Protection Selectivity
Maintaining proper coordination between upstream and downstream protection devices. Without appropriate grading and selectivity:
- Multiple breakers may operate for a single downstream fault
- Healthy feeders may trip unnecessarily
- Plant-wide outages can occur
- Restart and recovery time may increase significantly
Accurate Fault Level Assessment
Fault current levels are influenced by source strength, transformer impedance, network topology, and operating configuration. Incorrect assumptions during modelling can lead to:
- Inaccurate relay settings
- Equipment under-rating
- Unreliable protection performance
Limited Input Data & Network Representation
As commonly encountered in industrial projects, portions of the input data required validation and interpretation. This included:
- Verification of transformer and feeder data
- Appropriate representation of aggregated LV loads
- Validation of operating assumptions before simulation
Balancing Sensitivity and Stability
Protection systems must respond rapidly to faults while avoiding unnecessary operation. Achieving the correct balance between:
- Fast fault detection
- Grading margins
- Selective tripping
Technical Approach
System Modelling
A detailed network model developed in DIgSILENT PowerFactory using:
- Source parameters
- Transformer characteristics
- Feeder configurations
- Load representation
Short Circuit Simulations
Comprehensive fault studies across the network covering:
- Three-phase faults
- Line-to-line faults
- Single line-to-ground faults
- Fault current magnitudes at each bus
- Source contribution assessment
- Critical fault location identification
Relay Coordination Study
Detailed review of relay operating characteristics and grading:
- Relay pickup setting development
- Time-current curve coordination
- Grading margin verification
- Backup protection assessment
- Selective isolation verification
Validation of System Behaviour
Multiple fault scenarios simulated to verify:
- Selective tripping performance
- Absence of overlapping relay operating regions
- Stable system behaviour during fault events
Key Outcomes
The study delivered several important technical and operational improvements across the network.
Engineering Outcomes
Accurate short circuit level assessment across all voltage levels
Coordinated relay settings with selective operation philosophy
Identification and mitigation of potential protection miscoordination issues
Improved backup protection performance
Enhanced discrimination between upstream and downstream feeders
Operational Benefits
Reduced risk of plant-wide outages
Improved commissioning readiness
Reliable fault clearing capability
Stable system operation during disturbances
Minimised potential rework and operational delays during commissioning
Project Delivery
The study was completed within the committed project schedule following receipt of final input data.
Delivery
Protection Studies for Reliable Industrial Operations
Short circuit and relay coordination studies are fundamental to the safe and reliable operation of industrial power systems. For utilities, EPC contractors and industrial operators, protection studies are not simply about relay settings — they are about ensuring the electrical system responds correctly when abnormal conditions occur, protecting equipment, maintaining operational continuity, and reducing overall system risk.
